Product Details:
Payment & Shipping Terms:
|
| Product Name: | Toilet Tissue Paper Machine | Place Of Origin: | China |
|---|---|---|---|
| Per Weight: | 14Pa-35g/m2 | Designed Speed: | 250m/min |
| Working Speed: | 140-400m/min | Nominal Capacity: | 10-1T/D |
| Payment Term: | L/C,T/T | Delivery Time: | Within 30 Days |
| High Light: | Pulp Molding Machine,pulp molding equipment |
||
3900mm Width Tissue Paper Production Line
1. Tissue Paper Production Line Quick Details
Condition: New
Type: Toilet tissue paper making machine
Computerized: Yes
Place of Origin: Hebei, China
Brand Name: Huatao
Model Number:1575mm
Voltage: 380V
Power(W): 15KW
Dimension(L*W*H): Configuration
Weight: 2000KG-5800KG
Certification: CE/ISO9001
Product name: Toilet Tissue Paper Machine
Material: Carbon steel
Raw material: Waste Paper/Wood pulp
Trimmed width(mm): 1575-3600
Production capacity(t/d): 5-50
Output paper: Toilet Paper Tissue Paper Napkin Paper
Application: Paper Industry
Color: Optional Color
Machine type: Recycled Paper Pulp
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: One Year
| Item / PM type | 1575 | 1880 | 2400 | 2900 | 3500 | 3900 |
| Design Speed (m/min) | 250 | 250 | 250 | 250 | 250 | 250 |
| Working Speed (m/min) | 160-230 | 160-230 | 160-230 | 160-230 | 160-230 | 160-230 |
| GSM Range (g/m2) | 13-30 | 13-30 | 13-30 | 13-30 | 13-30 | 13-30 |
| Capacity | 4-6 | 5-8 | 7-10 | 8-12 | 10-15 | 11-18 |
| Diameter of Dryer (mm) | Φ2500-3000 | Φ2500-3000 | Φ2500-3000 | Φ2500-3000 | Φ2500-3000 | Φ2500-3000 |
| Motor (kw) | 37-45 | 45-55 | 55-75 | 75-90 | 90-110 | 90-110 |
| Gauge(mm) | 2400 | 2800 | 3400 | 3900 | 4500 | 4800 |
2. Tissue Paper Production Line Application
Mainly for the production of manufacture paper with pulp 14-35 g / ㎡, toilet paper. Paper napkin base paper
3. Tissue Paper Production Line Crafts Parameters
Pulp: wood pulp plate, waste paper etc as raw material
come out from wire case : 18-20％
Before go through MG cylinder : 36-40％
Come out from MG cylinder : 90-94％
Finish tissue : 90-94％
4. Tissue Paper Production Line Supporting parameter
AC voltage : 380V；50Hz
Working pressure: 0.2Mpa
Working pressure: 0.5Mpa
Working pressure:0.3Mpa
5. Tissue Paper Production Line Technical Parameters
Paper weight: 18-30g/m2
MG cylinder motor: 95kw
Roll-cylinder motor: 7.5kw
Total:102.5Kw
Automatic High Speed Toilet Paper/ Maxi Roll Rewinding Machine is for toilet paper roll/maxi roll processing.
Machine have core feeding unit, can do both with and without core. Raw material from jumbo roll after full embossing or edge embossing, then perforation, end cutting and spray the tail glue become a log. Then it can working with cutting machine and packing machine to become the finished products. The machine is controlled by PLC, people operate it through touch screen, the whole process is automatic, easy to operate, lower the man cost. And Our machine can special-made according to clients' requirements.
