Single Effect Fiber Seperator Turbo Pulp Screening Equipments



Application:



Used for further breaking the waste pulp broken by hydrapulper,at the same time separating the light and heary impurities from the pulp.


Advantages:





1. Special-shaped impeller and conic shell body can benefit by light and heavy impurities to remove.
2. Be able to equip deflaker with it, which can avoid breaking impurities and reduce load of back screening equipment.

3. Be able to increase hole dia. of extraction disc of hydrapulper to increase the capacity of breaking system.


Specification:


Type HTDX-62 HTDX-72 HTDX-88 HTDX-98 HTDX-110 HTDX-125 HTDX-135 HTDX-150
Capacity: t/d 20-40 50-70 70-90 100-140 140-200 200-280 280-320 300-400
Inlet Consistency: % 2-4
Inlet Pressure:MPa 0.15-0.25
Screen Slot dia: mm φ3-4.5
Impeller Diameter:mm φ620 φ720 φ880 φ980 φ1100 φ1250 φ1350 φ1500
Power of motor: kw 37 45 55 75 110 160 200 250
