Multi Bag Filter Used in Industrial Water Industry

Large Image : Multi Bag Filter Used in Industrial Water Industry

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	HT-068

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	By negotiation
Packaging Details:	standard export wooden box
Delivery Time:	15-25days
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	100 Set/month

Contact Now

Detailed Product Description

Goods:	Multi Bag Filter Used In Industrial Water Industry	Flow Rate:	1-45M3 /H
Filter Housing:	SS316L Or SS304	Bag Material:	PTFE Or Other
Filtration Precision:	0.5-3000um	Warranty Period:	1 Year
Surface Treatment::	Mirror Polish Or Sandblasting
Highlight:	industrial screening equipment , vibratory screening equipment

Multi Bag Filter Used in Industrial Water Industry

Introduction For Multi Bag Filter Used in Industrial Water Industry

Liquid gets into the filter bag from side or bottom feed holes. It is pushed by flowing power and steady pressure to make the bag open fully. The liquid spreads evenly across the whole inner side of the bag. All dirt stays inside the bag, and clean filtered liquid flows into transport tubes.

Working Principle For Multi Bag Filter Used in Industrial Water Industry

The liquid enters from the side or lower inlet of the filter bag.The filter bag is expanded due to the impact of the liquid and the uniform pressure surface.The liquid material is evenly distributed on the inner surface of the whole Filter bag.The filtered liquid passing through the filter bag and flow into the pipeline.The particle impurities are intercepted in the filter bag.

Multi Bag Filter Used in Industrial Water Industry 0

Technical Parameters For Multi Bag Filter Used in Industrial Water Industry

Filter Model	Filter Inner Dia.	Filter Height	Thickness	Filter Area
HT-D2	350mm	1000mm	4mm	0.5
HT-D3	450mm	1000mm	6mm	0.7
HT-D4	550mm	1000mm	6mm	1.0
HT-D5	650mm	1000mm	6mm	1.6
HT-D12	1000mm	1000mm	6mm	3
HT-D24	1200mm	1200mm	6mm	6

Feature For Multi Bag Filter Used in Industrial Water Industry

1.Operating temperature <200°C (depending on seal material);

2.Precision-manufactured from high-quality,pure SS304/316L stainless steel;

3.Quick-opening lid design reduces labor costs;

4.Optimized support basket openings increase flow rate and filter bag life;

5.High-quality butt-weld connections provide strength and corrosion resistance;

6.Oval bottom provides a perfect fit for the filter bag;

7.Multiple models with different filter areas are available to meet various flow requirements;

8.Matte sandblasted exterior surface for an elegant and easy-to-clean look;

9.Mirror-polished interior surface meets sanitary requirements;

10.O-type elastomeric seal seals the housing for easy tightening and durability;

11.High-precision filtration,suitable for all fine particles and suspended solids,with a filtration range of 0.5 to 200 microns.

Application For Multi Bag Filter Used in Industrial Water Industry

Bag filter is mainly used to filter impurities in water,beverages and chemical Liquids.
