| Product Name: | Drive Roll | Frame Material: | Carbon Steel Spraying, Stainless Steel, Aluminum Profiles |
|---|---|---|---|
| Power Mode: | Speed Reduction Motor Drive, Electric Roller Drive, Etc. | Roller Diameter: | 38、50、60、76、89mm |
| Hardness: | 18A-100A | Turning Inside Radius: | 300、600、900、1200mm |
High Strength, Excellent Abrasion Resistance Drive Roll for Warehouse logistics
Drive roller Description
The drive roller is composed of composite roller, connecting plug and roller shaft, which is a hollow body with simple structure. The composite roller is made of the outer layer of wear-resistant rubber and FRP roller, and the composite roller is firmly connected to the roller shaft by the connecting plug. The lack of precision in the slit of the driven rolls in the sector section can cause an increase in the deviation level in the center of the cast billet and affect the quality of the cast billet.
Drive roller Specification
| Product name | Drive roll |
| Structure form | Horizontal conveying, inclined conveying and turning conveying |
| Turning inside radius | 300,600,900,1200mm |
| Roller diameter | 38,50,60,76,89mm |
| Frame Material | Carbon steel spraying, stainless steel, aluminum profiles |
| Power Mode | Speed reduction motor drive, electric roller drive, etc. |
| Transmission method | Single sprocket, double sprocket, O-belt, flat friction drive belt, timing belt, etc. |
| Roller speed control mode | Variable frequency speed control, stepless speed change, etc. |
Drive roller Features
1. The roller set has glossy surface and rubber surface, and the shape of the rubber surface can be divided into glossy rubber, herringbone rubber and diamond-shaped rubber to meet different process requirements.
2. All rollers are equipped with integral bearing seat and grease lubrication.
3. The roller shaft material is 45 steel, the bearing seat has cast iron parts cast steel parts, the cylinder body is welded parts.
4. The roller structure is reasonable, easy to select, reliable performance and long service life.
Drive roller Advantages
1. High strength
2. Excellent abrasion resistance
3. Good elasticity
4. Oil resistance
5. Low temperature resistance
6. Good solvent resistance
