Poly Ripple Rectangular Shape Aperture Vibrating Screen Wire Mesh
1,Vibrating Screen Wire Mesh Producrion Description:
2,Vibrating Screen Wire Mesh Specification:
① Progress Harp Type K
This type of screens is made of round wavy, wires, curved in the horizontal working plain. Angle between the arms equals 90.
Working size of W opening is created by diameter of the circle written into this opening. Wires placed one next to another create
openings similar to a square. Working wires are buckled together with transversive wires using polyurethane, rubber or wires
inside plastic cover.
Opening sizes: 1.5 - 35 mm
Ø Wire: 0.8 - 6.3 mm
② Progress Harp Type T
They are produced with wires of round diameter – straight and wavy placed alternately on the horizontal working surface. Wave
spread span equals 90 or 60 . Working size of W opening is created by the diameter of the circle written into this opening.
Straight, round wires have a slightly larger diameter then wavy ones. This series of screens characterizes with high ability to
withstand heavy loads (owing to very well stretched straight wires)and good self-cleaning effect, obtained by self – oscillation
of wavy wires. Wires in this series of screens can be connected with each other using wire knots, polyurethane, rubber or
transverse wires inside plastic cover.
Opening sizes: 1.2 - 14 mm
Ø Wire: 1 - 4 mm
Q: What is the delivery time?
A:It is according to your quantity,normally 7 to 10 days;
Q:What is the advantages com pared to other suppliers?
A:The unique full automatic roller production line, high machining accuracy, uniform and stable quality, which can realize
continuous and efficient professional production, so we can provide good quality product and service to our customers.
Q:Can we visit your company?
A:No problem, we are look forward to your arrival and we will lead you to visit our factory.
Q:What's your trade term ?
A:EXW , FOB , CIF , CFR etc can be available
Q:Can I ask for samples for test purpose ?
A:Yes , it is welcomed . And according to our company policy , the sample fee & shipping cost need to be paid by your end , but we
can refund the sample fee upon receipt of your trial order .
Q:Can I OEM my screens ?
A:Yes , OEM material , size , color, package etc can be acceptable.
Q: Can I order 1 piece?
A:Yes , as our MOQ is 1 piece.
