High Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries

Large Image : High Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	CE, ISO
Model Number:	HTGE08

Payment & Shipping Terms:

Minimum Order Quantity:	20tons
Price:	1450-3000 USD/ ton
Packaging Details:	wooden pallet
Delivery Time:	15-30days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	200tons per month

Contact Now

Detailed Product Description

Product Name:	High-Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries	Raw Materials:	Premium Needle Coke And High-grade Coal Tar Pitch
Current Density:	Up To 25A/cm² For High-power Applications	Ash Content:	≤0.25%, Ensuring Purity In Smelting
Thermal Expansion Coefficient:	Low, Minimizing Thermal Stress Fractures	Mechanical Strength:	High Resistance To Breakage During Handling And Use
Electrical Resistivity:	Low For Efficient Current Transmission	Diameter Range:	400mm - 800mm, Customizable Lengths Available
Oxidation Resistance:	Coated With Specialized Anti-oxidation Layer	Operating Temperature:	Up To 3,500°C
Highlight:	HP eaf electrode , HP eaf graphite electrodes , HP electric arc furnace graphite electrodes

High-Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries

Description For High-Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries:

Engineered for superior conductivity and extended lifespan, our HP Graphite Electrodes optimize metallurgical operations, reducing consumption and enhancing efficiency in high-power electric furnaces.

Specification For High-Performance HP Graphite Electrodes For Intensive EAF Steelmaking And Foundries:

Items		Unit	Diameter ( mm )
			200-300mm	Typical Value	350-400 mm	Typical Value	450-500 mm	Typical Value	550-700 mm	Typical Value
			8-16 Inch		14-16 Inch		18-20 Inch		22-28 Inch
Specific Resistance≤	Electrode	μΩ.m	6.6	6.0	6.5	6.0	6.3	6.0	6.0	6.0
	Nipple		5.5	4.8	5.2	4.8	5.0	4.8	4.8	4.8
Bending Strength ≥	Electrode	MPa	10.0		10.5		10.5		10.5
	Nipple		16.0		18.0		18.0		18.0
Young's Modulus ≤	Electrode	GPa	12.0		14.0		14.0		14.0
	Nipple		16.0		18.0		18.0		18.0
Bulk Density	Electrode	g/cm³	1.68	1.72	1.70	1.72	1.72	1.72	1.72	1.72
	Nipple		1.72	1.80	1.75	1.80	1.76	1.80	1.80	1.80
(100℃-600℃) CTE ≤	Electrode	X10 -6/℃	2.4		2.2		2.2		2.2
	Nipple		2.2		1.63		1.6		1.6
Ash Content ≤		%	0.3		0.3		0.3		0.3
Note: Ash content is only for reference.
