|Driven Type:||Electric||Voltage:||380V 50HZ|
|Power:||3KW||Application:||Cardboard Production Line|
|Function:||Carton Packer||Warranty:||12 Months|
corrugated carton making machine,
Corrugated Carton Box Machine
1600mm Electrical Shaftless Mill Roll Corrugated Carton Box Machine is electric control of the paper reel lift-lower, clamp, loosen, movement, contra position operated . It is the first step for corrugated baord production .
|Kraft paper range||Max. Width: 1800mm Min.:900mm|
|Max Weight||2000Kg (One side)|
|Reel Stand driven||electric|
|Pneumatic Source Pressure(Mpa)||0.4---0.8Mpa|
|Reel Paper Nipping Motor Power||500W*4pcs|
|Lifting Motor Woking Power||1.5KW 380 V 50 Hz|
|Nominal voltage||380V 50Hz Short Time(S2) Working Type
Structure and Features:
1, Reel Stand driven by electric
2, Symmetrical structure,can carry two kraft paper at one time,which can work without brake.
3, Reel paper lift-lower, clamp, loosen, movement, contraposition operated by electric mechanic.feeding kraft / reel paper quickly.
4, Single slide with four arms can support two paper mill rolls on both arms simultaneously.
5. Round plate manual brake can adjust the web tension at all times.
3/5/7-layer Corrugated Cardboard Production Line & Single Lacer production line
Related parts : Corrugated cardboard conveyor belts are used specially for corrugated cardboard production lines .After passing through a single-side corrugating machine ,corrugating medium becomes corrugated under pressure and bonds together with the outer facing to constitute a single-side corrugated cardboard ,which may be multiplied into three -layer .five layer or seven-layer corrugated cardboards after gluing .The conveyor belt , which is made of several types of synthetic fiber through fine knitting ,shall be installed on top of the thermal plate and the cooling section .During operation , the conveyor belt shall endure high temperature ,high pressure and strong friction to ensure cardboards could be bonded accurately and dried in due time , thus providing a safe and reliable guarantee for the smooth operation of the corrugated cardboard production line .
Kraft paper feeding ground rack & trolly
1, To feed the kraft paper to reel stand.
2, The whole body of rack is under the ground, main frame: Model 14 channel steel with ¢ 20mm drawing bar weld together,overall length 4500mm.
3, Two racks for one reel stand to feed the kraft paper at both side.
