Aerogel Blanket HT650 Suitable for High Temperature Insulation Applications
Product Attributes
| Attribute |
Value |
| Application |
Pipe insulation |
| Color |
Maroon, White, Grey |
| Package |
Plastic Film, Carton board |
| Stock |
Available |
| Delivery |
Within 3 Days |
| Service |
24 Hours, 1 Weeks, 365 Days |
Product Description
Aerogel Insulation Blanket HT650 is extremely hydrophobic and breathable. By keeping the underlying asset drier for longer, Aerogel Insulation Blanket HT650 offers world-class leading CUI (corrosion under insulation) defense.
Quick Details
| Model |
HT650 and HT200 |
| Color |
Maroon, White, Grey |
| Thickness |
3mm / 5mm / 6mm / 10mm |
| Width |
1500mm |
| Length |
3mm - 57m / 5mm - 42mm / 6mm - 38mm / 10mm - 25m |
| Hydrophobic |
Yes |
| Use of Temperature |
-200℃ - 650℃ |
| Density |
220kg/m³±20% |
| 25℃ Thermal Conductivity mW/(m*K) |
18 - 23 mW/(m*K) |
Applicable Areas
- Prefabricated pipe with insulation Tanks, vessels and other equipment
- Steam pipelines in petroleum production
- Pipelines in thermal power plants, petrochemical plants and chemical plants
- Medium and high temperature industrial furnaces and removable escape capsules
- Automobile, high-speed train, and subway
- Building and constructions
Application Advantages
- Superior Insulation Performance: 2~5 times better than traditional insulation products with longer service life
- Reduced Insulation Thickness: For the same insulation performance, just take a portion of thickness of traditional material
- Hydrophobicity and Fire-proof: Repel water from penetrating into pipes, equipment, A1 rating of fire-proof
- Easy Handling: Lightweight, easily cut and sewn to fit for different shapes of pipes and equipment, less labor for installation
- Transportation Costs Savings: Lower packing volume and lower weight can greatly cut down logistics costs
Service
24/7 Period On Line. Enough Stock to Catch your delivery.
Frequently Asked Questions
We work together with ASPEN, DON'T need to change others?
As we know, ASPEN is the largest aerogel manufacturer and has most popular name value in current business market. Even though there are many other aerogel manufacturers in addition to ASPEN, it's not easy to replace ASPEN. However, at the same time, it's true that many customers (EPCs) feel uncomfortable for ASPEN's high price strategy. In this regards, how competitive price we can supply will be the key factor. Please check our brief price, it was 20% down from ASPEN. If you can see proper advantage on a price basis, Can you try to approach to your clients?
Which kind of aerogel do you have?
We have two series for Aerogel Blanket: One is HT650 Series, Other is HT200 Series: HT650, It was Aerogel insulation blanket with fiberglass, similar with Pyrogel XT and Spaceloft (mainly used for the hot & heat insulation and building insulation, working temperature from -200℃ to 650℃), the thermal conductivity from 0.018-0.023 W/m.k. HT200. Aerogel insulation blanket with Aluminium foil, similar with Cryogel Z (mainly used for the cold insulation, such as LNG, Working temperature from -190℃-150℃), the thermal conductivity from 0.019-0.021 W/m.k.
Can you sent the samples for test?
Certainly the samples can be sent to you, and with free cost. size with 10*15cm is this workable for your testing? Please share with me about your office address and contact information. thanks
What certificate do you have for aerogel blanket?
Our Aerogel Blanket is strictly according to ASTM D 1728 Standard. and can meet Reach, ROHS standard. MSDS also can enclosed for your reference.
What is your Package?
For the aerogel Blanket, we package it with Papertube and PE Film and paper board.
Company Information
We don't just strive for perfection, we make it a reality for our customers. With over ten (10) years of experience in our export team, it has become our duty to become even more cost competitive for customers, without any sacrifice to quality and reliability whatsoever.
HUATAO GROUP was found in 2008 by the owner Floyd. As the Group company, The boss collect all factories in together and establish HUATAO GROUP. HUATAO as the manufacturer and trader agent of a wide range of products and provide the professional services all over the world which relate to All kinds of Aerogel Blanket, can be used into Oil Exploration, Oil Refining System, City Heat Net Project, Hot Pipe Cover etc.
Our Main Products
- Aerogel Blanket
- Aerogel Panel
- Aerogel Particles and Powders
Our team of senior engineers can organize the best commodity source for you. By supplying the best Chinese products, Professional design and responsible attitude on service, we devote to creating our unique brand "HUATAO" in global. Since the establishment, "HUATAO" products have been supplied to more than 20 countries and set up the agencies. And our products and service have been recognized and trusted by the end users all the way. We believe, once we have the cooperation, "HUATAO" will be your most reliable partners in your road to success. Because of trust, business will be simple.
