Product Details:
Payment & Shipping Terms:
|
| Overall Size (m): | 7*(2.3-4)*1.8 | Weight Of Equipment: | 4000-8000kg (approximately) |
|---|---|---|---|
| Power(W): | 300kw | Production Speed: | 180∼200/ M/min |
| Highlight: | Pulp Molding Machine,pulp molding equipment |
||
2400mm Fully Automatic Tissue Paper Making Machine
2400mm tissue paper making machine paper core machine with green environmental protection,tissue paper making machine
1.2400mm tissue paper making machine paper core machine description
Machine Name: Fully-Automatic Toilet Paper Machine
This machine is used for producing Toilet Paper with high capacity and high quality Toilet Paper machine
2.2400mm tissue paper making machine paper core machine Function & Assemble Parts :
1. the machine is with international advanced plc programmable controlling technical, frequency conversion speed-regulator, electronic brake and man-machine interface operation table. the multi functions mounting on this machine has won the favor and credit among users by their profound practicability.
2. under european ce standard designing, passed ce certificate, with ce or ul certificate for electric parts and with safety device, such as, safety-guard door, emergency stop and so on.
3. most of parts are precisely processed by numerical-control machine; the key mechanical parts are under cnc processing; while the main outsourcing parts are world famous brand.
4. automatic roll core splicing unit without manual core feeding; auto edge trimming, glue spraying and sealing synchronously in one time, which had materialized the popular technique of edge-trimming and tail-gluing as well as auto pushing out the final products after rewinding;
5. monitoring system on broken paper or torn edge under high-speed running the equipment; jumbo roll tension controlling system; pneumatic lifting the jumbo roll.
6. it can work together with color printing and rewinding machine or glue laminating unit to produce kitchen towel
3. 2400mm tissue paper making machine paper core machine Main Technical Parameter:
| Machine Model | 1092 | 1575 | 1760 | 2200 | 2500 | 2800 |
| mm Width (mm) | 1350 | 1750 | 1900 | 2150 | 2450 | 2750 |
| (mm) Finished Products Diameter | Φ 60∼150 (Tightness can be adjustable) | |||||
| (mm) Finished Products Inner Diameter | Φ32∼50 mm | |||||
| (mm) Jumbo roll diameter (mm) | Φ 1200() (Other sizes can be ordered) | |||||
| Jumbo Roll Inner Diameter | 3,76.2 mm () (other sizes can be ordered) | |||||
| (mm) Perforation distance (mm) | 4(blade),90∼160mm2(blade),180∼320mm | |||||
| Production speed | 180∼200/ m/min | |||||
| Parameter set | Touching-screener Multi-menu Man-machine Interface Operation System | |||||
| Programmable controller | PLC Mitsubishi PLC program | |||||
| Mechanical driving |
, Driven by stepless speed-regulator to guarantee the precise length of final products. |
|||||
| Embossment unit | ,, Single embossment, Double embossment, Steel to steel embossment; | |||||
| Embossment down roller | ,, Felt roller, paper roller, rubber roller | |||||
| Jumbo roll stand | 1-3 1-3 plies (ply quantity can be ordered) | |||||
| Air pneumatic system |
3,5kg/cm2 Pa() 3 Pa (air-compressor), the minimum pressure 5kg/cm2 pa (customers should be prepared by themselves) |
|||||
| Power | 5.5-15KW (Frequency speed-regulate ) | |||||
| (m)(L×W×H) Overall size | 7 X (2.3-4) X 1.8 | |||||
| Weight of equipment | 4000∼8000kg (approximately) | |||||
| Chosen items (Should be ordered separately) | ||||||
| Embossment | ,, Single embossment, double embossment, steel to steel embossment | |||||
| Embossment down roller | ,, Felt roller, paper roller, rubber roller | |||||
| Jumbo roll stand | 1-3; 1-3 plies | |||||
| Jumbo roll stand driving | Driven by variator | |||||
| Rewinding unit | Non-core unit | |||||
| Printing unit | Single color heliotype printing unit | |||||
| Side rolling embossment | Steel to steel | |||||
| Perforation mode | Air pneumatic separating unit | |||||
| Smooth embossment | , Steel to steel, Steel to rubber ; | |||||
| Remote telecom service system | Should be ordered separately | |||||
4. 2400mm tissue paper making machine paper core machine Products Quality Requirement & Machine Inspection Request:
1.There is no wrinkle and no breaking holes on rewinding products;
2.Rewinding diameter should reach to the designated quantity;
3.Slitting length can be made by order, the slitting is straight with no slanting;
4.Glue sticking is fixed;
5.Embossment is clear with no delamination;
6.Machine inspection requirement: speed 0-180/min;
7.Rejected products rate ≤0. 5% (excluding to cut the left-over)
