610x610mm Polyurethane Screen Mesh for Mining with High Screening Efficiency and Long Service Life

Large Image : 610x610mm Polyurethane Screen Mesh for Mining with High Screening Efficiency and Long Service Life

Product Details:

Place of Origin:	China
Brand Name:	HUATAO
Model Number:	HT-013

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	USD 35-45 per piece
Packaging Details:	air bubble film + wooden box
Delivery Time:	7 - 10 working days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	10000 pieces per month

Contact Now

Detailed Product Description

Material:	Polyurethane	Size:	610mm610mm /305mm305mm
Type:	LINEAR	Feature:	High Screening Efficiency
Usage:	Separation Screening	Function:	Screening\separation\sorting\sieving
Voltage:	220V / 380V / 415V / 450V	Warranty:	More Than 5 Years, 12 Months
Open Area Rate:	28-40%	Color:	Red,yellow,green
Highlight:	mining vibrating screen mesh , polyurethane vibrating screen mesh , 610x610 Vibrating Screen Mesh

610x610 Polyurethane Mining Vibrating Screen Mesh

High quality polyurethane mining screens designed with an innovative structure that utilizes a utility model fastening connection system. This system integrates the supporting beam and polyurethane panel as a complete unit through rail support, ensuring both connection strength and operational efficiency.

Key Advantages

This structural design offers simplified installation and replacement while maintaining connection integrity, resulting in improved separation and screening efficiency with reduced operational intensity.

Technical Specifications

Mesh Size	Standard Type	Effective Type	Long Service Type
Diagrid mm	Aperture Ratio %	Diagrid mm	Aperture Ratio %	Diagrid mm	Aperture Ratio %
8	4	14	3	53	6	33
10	4	51	3	59	6	39
12	6	44	4	56	8	36
14	6	49	4	60	8	40
16	6	53	4	64	8	44
18	7	52	6	56	10	41
20	7	55	6	59	10	44
22	8	54	6	62	10	47
24	10	50	8	56	12	44
27	12	48	10	53	12	48
30	12	51	10	56	12	51

Additional Specifications

Material: Polyurethane material and steel frame
Thickness: 25mm - 60mm
Hole type: Square, rectangular, round and other types available
Hole size: 2.5mm - 130mm
Panel width: Maximum 1.5m
Panel length: Maximum 3m
Hook type: Metal or polyurethane
Hook direction: Transverse or longitudinal
Color: Red, yellow, blue and custom colors available

610x610mm Polyurethane Screen Mesh for Mining with High Screening Efficiency and Long Service Life 1

Polyurethane Characteristics

Long Service Time: Service life exceeds 8 times that of ordinary metal products and 3.9 times longer than rubber products
Large Bear Capacity: Excellent resilience, high impact absorption, wear resistance, and tensile strength provide 2.5 times greater capacity than rubber and stainless products
High Sieving Efficiency: Rectangular mesh slots ensure proper size distribution and improve screening efficiency
No Blocking: Resilience nature prevents aperture blockage
Low Noise: Reduces noise by 5-20 decibels compared to metal mesh
Low Maintenance Cost: Easy installation, simple replacement, and long service life minimize maintenance expenses
Large Ore Capacity: Capable of sieving more than 200,000 tons of ore
Durability: Abrasion resistant, tear resistant, and corrosion resistant

Applications

Polyurethane Flip Flop Screen Mats utilize quality elastomers to deliver superior performance for screening moist or humid materials. Suitable for processing wood chips, building rubble, plastic, and custom materials as specified by customers.

Ideal for screening applications including:

Iron ore at 6mm with 15% moisture
Raw sand at 3mm with 6% moisture
Compost at 10mm with 50% moisture
Slag at 3mm with 10% moisture
