3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building

China HUATAO LOVER LTD certification
China HUATAO LOVER LTD certification
Huatao company is a very good company , I am very willing to cooperate with you, safe, efficient, professional, honest, happy! Thank you for providing me with stable service and products. -----EUROPAT


I'm Online Chat Now

3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building

3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building
3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building
video play

Large Image :  3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building

Product Details:
Place of Origin: China
Brand Name: HUATAO
Certification: CE , ASTM1789
Model Number: HT650
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square Meters
Price: USD 10 - 50 Per Square Meter
Packaging Details: Plastic Film Inside, Shock Absorption Film Packaging,1.5m x 42m Per Roll, One 20ft loading with 46rolls (2898m2) One 40ft loading with 118rolls(7434m2)
Delivery Time: 5-8 Work Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: Stock, 10000m2 Per Week
Detailed Product Description
Specification(mm): 5-6/10*1500*25000 Color: White
Fire Rating: A-class Non-combustible Density(kg/m3): ≤220
Delivery: Within 3 Days Material: Silica Aerogel
High Light:

10mm thickness flexible aerogel blanket


building flexible aerogel blanket


3mm thickness aerogel insulation sheet

    3-10mm Thickness Aerogel Silica Sheet Cyrogel Hydrophobic Aerogel Cold Insulation Blanket For Building



1. Aerogel Insulation Blanket Product Information:


HT200 series aerogel blanket is a kind of flexible, low-temperature, and high-efficiency cold-proof felt. This material combines nano-aerogel with special fiber to produce flexible, ultra-low thermal conductivity, high-efficiency thermal insulation felt, suitable for liquid nitrogen, LNG, and other low-temperature industrial pipes, tanks, and equipment are cold-proof and heat-insulating. They are the best products in cold insulation materials and are ideal for customers to pursue a better low-temperature cooling effect and lower energy consumption.


2. Aerogel Insulation Blanket Quick Details:


Model HT650 and HT200
Color Maroon , White , Grey
Thickness 3mm / 5mm / 6mm / 10 mm
Width 1500mm
Length 3mm - 57m / 5mm - 42mm / 6mm - 38mm / 10mm - 25m
Hydrophobic Yes
Use of Temperature -200℃ - 650℃
Density 220kg/m³±20%
25℃ Thermal Conductivity mW/(m·K) 18 - 23 mW/(m·K)


3. Aerogel Insulation Blanket Applicable areas:


Ⅰ. Prefabricated pipe with insulation Tanks,


Ⅱ. vessels and other equipment Steam pipelines in petroleum production,


Ⅲ. Pipelines in thermal power plants, petrochemical plants and chemical plants,
Ⅳ. Medium and high-temperature industrial furnaces and removable escape capsules,
Ⅴ. Automobile, high-speed train, and subway,


Ⅵ. Building and constructions
4. Aerogel Insulation Blanket Application advantages:

1. Good structural strength:

long service life and reusable after being detachable.


2.Convenient construction:

lightweight, easy to cut and sew to adapt to various shapes of pipes and equipment insulation, and less time and labor required for installation.


3. Excellent water repellency and excellent fire resistance:

the overall water repellency of the material can effectively prevent the corrosion of liquid water from contacting the surface of pipes and equipment and prevent it. The material has a reduced thermal insulation effect due to water seepage.


4. Excellent ultra-low temperature stability:

It maintains good flexibility at ultra-low temperature without cracking and resists internal stress caused by pipe expansion and contraction.


5. Excellent cold insulation performance:

Ultra-low thermal conductivity greatly reduced thickness required, especially suitable for applications with limited space.

3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building 0
3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building 1
3-10mm Thickness Flexible Aerogel Blanket / Aerogel Insulation Sheet For Building 2
1. We work together with ASPEN, DON'T need to change others?


As we know, ASPEN is the largest aerogel manufacturer and has the most popular name value in the current business market.
Even though there are many other aerogel manufacturers in addition to ASPEN, it’s not easy to replace ASPEN.

However, at the same time, it’s true that many customers ( EPCs) feel uncomfortable for ASPEN’s high price strategy.
In this regard, how competitive the price we can supply will be the key factor.

Please check our brief price, it was 20% down from ASPEN.
If you can see the proper advantage on a price basis, Can you try to approach your clients?


2. Which kind of aerogel do you have?

We have two series for Aerogel Blanket: One is HT650 Series, Other is HT200 Series:

HT650, It was Aerogel insulation blanket with fiberglass, similar to Pyrogel XT and Spaceloft ( mainly used for the hot &heat insulation and

building insulation, working temperature from -200℃ to 650℃), the thermal conductivity from 0.018-0.023 W/m.k


HT200. Aerogel insulation blanket with Aluminium foil, similar to Cryogel Z ( mainly used for the cold insulation, such as LNG, Working

temperature from -190℃-150℃ ),the thermal conductivity from 0.019-0.021 W/m.k


3. Can you send the samples for the test ?

Certainly, the samples can be sent to you, and with free cost. size with 10*15cm is this workable for your testing?
Please share with me your office address and contact information. thanks


4. What certificate do you have for aerogel blanket?

Our Aerogel Blanket is strictly according to ASTM D 1728 Standard. and can meet Reach, ROHS standard.

MSDS also can enclose for your reference.


5. What is your Package?

For the aerogel Blanket, we package it with Papertube and PE Film and paper board


Company Information:


We don’t just strive for perfection, we make it a reality for our customers, With over ten (10) years of experience in our export team, it has become our duty to become even more cost-competitive for customers, without any sacrifice to quality and reliability whatsoever.


HUATAO GROUP was found in 2008 by the owner Floyd, As the Group company, The boss collects all factories in together and establish HUATAO GROUP. HUATAO as the manufacturer and trader agent of a wide range of products and provide professional services all over the world which relate to All kinds of Aerogel Blanket, can be used in Oil Exploration, Oil Refining System, City Heat Net Project, Hot Pipe Cover ect.


Our Main products including:

1) Aerogel Blanket

2) Aerogel Panel

3) Aerogel Particles and Powders


Our team of senior engineers can organize the best commodity source for you. By supplying the best Chinese products, Professional design, and responsible attitude on service, we devote to creating our unique brand “HUATAO” globally. Since the establishment, ” HUATAO ” products have been supplied to more than 20 countries and set up the agencies. And our products and service have been recognized and trusted by the end users all the way. We believe, once we have the cooperation, “HUATAO” will be your most reliable partner in your road to success. Because of trust, the business will be simple.
