Product Details:
Payment & Shipping Terms:
|
| Product Name: | 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers | Size: | As Your Request |
|---|---|---|---|
| Application: | Thermal Insulation | Treat Temperature: | 2500℃ |
| Thermal Conductivity: | 0.08-0.22W/m.k | Material: | Carbon Fiber |
| High Light: | heated furnace chambers graphite soft felt,1.5mm thick graphite soft felt,heated furnace chambers soft graphite felt |
||
1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers
Description Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers are used in high temperature furnaces, and their main function is to keep warm 3000°C. Due to the low density of the material, the mass of the thermal insulation layer is also light. The thickness ranges from 1.5 to 15mm and the resistance is also higher, which ensures the best thermal insulation design for various systems. In addition, we can also produce 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers in custom sizes according to your specific requirements.
Specification Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
| Product Name: | 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers |
| Carbon Content: | ≥99% |
| Thermal Conductivity: | 0.08-0.14W/m.k |
| Volume Density: | 0.12-0.14g/cm3 |
| Tensile Strength: | 0.14Mpa |
| Crushing stress at 10% compression: | 8-10N/cm2 |
| Processing Temperature: | 2500ºC |
Application Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
Feature Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
1.Low ash content,High carbon content,Low gas evolution.
2.Excellent heat insulation,Low thermal conductivity.
3.Long life time,Good anticorrosion,High oxidation resistance
4.Easy Handling,Good Strength.
Detail Photo Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
Package Of 1.5mm Thick Graphite Soft Felt For Heated Furnace Chambers:
