High Strength HTD5M Rubber Timing Belt Synchronous Belt Arc Tooth

Large Image : High Strength HTD5M Rubber Timing Belt Synchronous Belt Arc Tooth

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Model Number:	T006

Payment & Shipping Terms:

Minimum Order Quantity:	10 pcs
Price:	10-1000USD per pc
Packaging Details:	Standard exporting packing
Delivery Time:	7
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	10000pcs per day

Contact Now

Detailed Product Description

Color:	Black	Materials:	Rubber
Lifetime:	Long Enough	Samples:	For Free
Tooth:	Single SIde
Highlight:	High Strength Rubber Timing Belt , HTD5M Rubber Timing Belt , Arc Tooth Rubber Timing Belt

High Strength HTD5M Rubber Timing Belt Synchronous Belt Arc Tooth

Arc Tooth Timing Belt is a specially designed synchronous transmission belt with an arc-shaped tooth profile (HTD, RPP/HPPD, STPD/STS). It is specially designed for high torque and high-speed applications and is an alternative to the traditional trapezoidal tooth profile. The upgrade can provide reliable power transmission and motion control for the transmission system.

Technical parameters:

Tooth Profile	Type	Pitch(mm)	Tooth Height(mm)	Belt Thickness(mm)
HTD	2M	2.00	0.75	1.36
	3M	3.00	1.17	2.4
	5M	5.00	2.06	3.8
	8M	8.00	3.36	6.00
	14M	14.00	6.02	10.00
	20M	20.00	8.4	13.20
STPD/STS	S2M	2.00	0.76	1.36
	S3M	3.00	1.14	1.9
	S4.5M	4.50	1.71	2.81
	S5M	5.00	1.91	3.4
	S8M	8.00	3.05	5.3
	S14M	14.00	5.3	10.2
RPP/HPPD	P2M	2.00	0.76	1.36
	P3M	3.00	1.15	1.9
	P5M	5.00	1.95	3.5
	P8M	8.00	3.2	5.5
	P14M	14.00	6.00	10

Advantage:

1. High transmission stability: The arc tooth timing belt has a reasonable tooth groove design, which makes the synchronous pulley and the belt body more closely meshed, which can reduce the tooth skipping phenomenon in the transmission and the energy loss during the transmission process. This ensures the stability of the transmission.

2. Low noise: The tooth design of the arc tooth timing belt reduces the impact and vibration during the transmission process, thereby reducing the generation of noise and making the transmission more stable. This also enables it to withstand greater loads.

3. Long service life: The arc tooth timing belt is made of high-strength polyurethane or rubber material, which has good wear resistance and corrosion resistance and can maintain a long service life.

Photo Reference:

High Strength HTD5M Rubber Timing Belt Synchronous Belt Arc Tooth 0
