Double Shell Structure Cooling Roller with Q345 Material and High Heat Transfer Efficiency for Customizable Capacity

Large Image : Double Shell Structure Cooling Roller with Q345 Material and High Heat Transfer Efficiency for Customizable Capacity

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	COOLING ROLLER

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	20000USD/pc-50000USD/pc
Packaging Details:	Wooden Box
Delivery Time:	4-6 MONTH
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	50 PCS/Year

Contact Now

Detailed Product Description

Product Name:	Double Shell Structure Cooling Roller Chrome Coating BOPP	Key Words:	Cooling Roller, Ceramic Coating Cooling Roller, Anti-sticking Coating
Surface:	Chrome-coating, Ceramic-coating, Anti-sticking Coating	Flow-System:	Channels Between Inner And Outer Tube Separated With Welded Leading Spirals
Warranty Period:	1 Year	Capacity:	Customize As Customer Request
HS Code:	84779000	Material:	Q345
Highlight:	Double shell cooling roller Q345 material , Industrial roller high heat transfer , Customizable capacity cooling roller

Double Shell Structure Cooling Roller Chrome Coating BOPP

Product Description

The Double Shell Structure Cooling Roller Chrome Coating BOPP is engineered for superior performance in bi-oriented stretch film production, featuring advanced cooling technology with chrome-coated surfaces for enhanced durability and heat transfer efficiency.

Cooling Roller Technology

Modern cooling rollers in bi-oriented stretch film production utilize two primary internal configurations:

Double-Layer Single-Flow: Features outer shell, inner shell, and spiral baffle design. The working medium (water/thermal oil) enters through a single-flow heat transfer channel for effective heat dissipation.
Double-Layer Double-Flow: Incorporates dual-path heat transfer channels for higher efficiency, though with more complex manufacturing requirements and higher cost.

Technical Specifications

Construction Type	Double-shell
Flow-System	Channels between inner/outer tube separated with welded leading spirals
Disc/Shaft Construction	Shrinked and welded shafts and side discs from Q345B
Surface	Chrome-coating
Cylinder Form	<=0.1mm
Out of Roundness	<=0.1mm
Dynamic Balance	G2.5

Applications

Ideal for various industrial applications including:

Sheet, plate, and compound machines
Printing and plastic packaging machinery
Processing of materials including film, aluminum foil, glass, cloth, and decorative materials
Compatible with PVC, ABS, PP, PE, PT, PC plastics and various surface treatments

About Huatao Group

Founded in 2008, Huatao Group is a leading manufacturer of industrial rollers with over 15 years of expertise serving:

Paper Industry: Forming rollers, vacuum couch rollers, dryer cylinders
Plastic & Rubber: Chill rollers, MDO rollers, corona treatment rollers
Nonwoven Fabric: Cylinder rollers, embossing rollers, spreader rollers

Our products are exported to 96+ countries, backed by our commitment to innovation, reliability, and customized solutions for diverse industrial requirements.
