Anti-Clogging Polyurethane Flip Flow Screen Mat for Damp Sticky Coal Washing

Large Image : Anti-Clogging Polyurethane Flip Flow Screen Mat for Damp Sticky Coal Washing

Product Details:

Place of Origin:	China
Brand Name:	Huatao
Certification:	ISO9001, CE
Model Number:	PU Screen Panel
Document:	2026-Huatao Catalogue of Mi...on.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	5 Pieces
Price:	USD 35 - 45/Piece
Packaging Details:	Standard Export Packing
Delivery Time:	5-7 Days
Payment Terms:	T/T,Western Union,L/C,D/A,D/P
Supply Ability:	10000 Pieces Per Month

Contact Now

Detailed Product Description

Material:	Polyurethane Material And Embedded Steel Frame	Aperture Size:	Min.0.053mm
Type:	Ws85,Ls Series	Thickness:	30mm,40mm,50mm
Specification:	OEM	Production Capacity:	10000PCS/Month
Highlight:	Anti-clogging polyurethane screen mat , Flip flow screen for coal washing , Damp sticky coal screen panel

Anti-Clogging Polyurethane Flip Flow Screen Mat for Damp Sticky Coal Washing

Product Overview

The Anti-Clogging Polyurethane Flip Flow Screen Mat is a high-performance screening media engineered to solve the challenges of handling damp and sticky materials like coal, clay, and damp ores. Conventional screening systems often struggle with "blinding," where wet fines stick to the mesh and block the openings. Our flip-flow mats use a highly elastic MDI polyurethane that creates a "trampoline" effect, vigorously tossing the material and preventing it from sticking to the surface. This active cleaning mechanism is supported by a high tensile embedded steel frame (where applicable for attachment) and a reinforced polymeric cord structure that allows the mat to stretch and relax thousands of times per minute.

The service life of these mats is exceptional, providing 3 to 8 times more durability than metal-based solutions due to the inherent wear resistance of our specialized urethane formula. For coal washing and ore processing, the mats are typically provided in thicknesses of 30mm or 45mm, with custom slotted openings designed to maximize throughput while maintaining precise sizing. The mats are compatible with standard flip-flow vibrating machines and can be customized in various dimensions, such as widths of 500mm or 515mm, to fit the specific deck layout of your plant. This technology is particularly beneficial for municipal solid waste recycling and iron ore pellet screening, where material moisture content can vary significantly. By eliminating the need for manual cleaning and reducing the frequency of screen changes, these polyurethane flip-flow mats drastically improve the uptime and efficiency of modern coal preparation and mineral sizing operations.

Please find the applicaiton as below:

* Mining: Ideal for grading iron ore, copper, limestone, and granite.
* Coal Processing: Efficient dewatering and desliming in coal preparation plants.
* Aggregates & Quarries: High-precision screening of sand, gravel, and crushed stone.
* Recycling & Waste Management: Separation of construction debris and industrial waste.

Technical Specifications

Item	Vibrating Screens PU Screen Panel For Mineral Processing
Dimension (L*W)	300mmx 300mm 305mmx 305mm 300mmx600mm 300mmx800mm 300mmx 1000mm 305mmx610mm others can be designed
Color	Yellow;Red;Orange;Green as regular
Thickness	5mm;30mm;40mm;50mm as regular
Warranty	12 Months
Applicable Industries	Energy & Mining
Material	Polyurethane with steel frame/MDI/TDI
Screen Size	5mm;30mm;40mm;50mm as regular
Cell Type	Slot,Square,Round etc.
Connection Type	WS 85; Trellex LS; P-yramid; Rail; etc.

Connection Type

Key Features

Polyurethane materials for wear resistance
Self-cleaning apertures reducing pegging and blinding
Wide range apertures suit most applications
Various panel sizes to suit all vibrating screens
Different connection type for easy installation and replacement
High screening performance
Low noise operation
Long service life and durable construction

Our team

Huatao Group is a leading innovative mineral equipment solutions provider, dedicated to improving operational efficiency and productivity in the mining and mineral processing industries. We are always committed to providing high quality and customer satisfaction, and are committed to becoming a trusted partner for companies.

HUATAO GROUP boasts a specialized team dedicated to developing mineral equipments and parts. Our primary business encompasses vibrating screens, polyurethane screen, rubber screen panels, mineral crushers, beneficiation machinery and other mineral equipment parts. Furthermore, we specialize in custom engineering, precision manufacturing, quality assurance, after-sales support and continuous innovation. Our products are renowned for their durability, efficiency, and reliability. We also offer equipment installations, operational training, and a wide range of spare parts to ensure our clients' operations run smoothly. With advanced technology and a focus on sustainability, HUATAO GROUP stands as a leading player in the mineral processing industry. If you are looking for polyurethane screen panels manufacturers, please contact us for more information!

FAQ

Q: What's the lead time for orders?
A: Standard models ship in 15–30 days; customized units require 30–45 days.

Q: Do you provide after-sales service overseas?
A: Yes, we have partnered service centers in key regions. and can fly to your site for after-sales.

Q: Can I request a customized size and design?
A: Absolutely! We offer customized.

Q: What documents do you provide for export?
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).

Q: How do I place an order?
A: Contact us via email/phone/WhatApp for a quote, then confirm with a PO.
