Chrome Plated Hydraulic Cylinder Briquette Machine 8000 Hours

Chrome Plated Hydraulic Cylinder Briquette Machine 8000 Hours

Reduce waste and create profit with the HT-2600A Biomass Briquette Press. This machine processes peanut shells and almond shells into solid biofuel. Nut shells must be crushed to ≤10mm with moisture below 10%. The hydraulic system provides 25 tons of force without the wear issues of screw presses. Briquette diameter is adjustable 50-80mm. Length is 50-150mm. Capacity is 250-350 kg per hour. Motor power is 22kW. Machine dimensions are 2200×1200×1800mm. Request a quote today for this durable equipment.

The 2600A Hydraulic Biomass Briquette Machine converts agricultural and forestry waste into high-density solid biofuel briquettes. Unlike pellet machines that produce small pellets, this briquette press creates larger cylindrical logs (50-80mm diameter) ideal for industrial boilers, gasifiers, and heating stoves. The hydraulic system delivers consistent pressure without overheating, enabling 24/7 operation.

• Industrial Boiler Fuel: Replace coal with biomass briquettes in factories reducing carbon emissions by up to 80%
• Gasification Power Plants: Produce uniform feed material for biomass gasifiers
• Commercial Heating: Supply hotels schools and hospitals with cost-effective solid fuel
• Waste Management: Convert sawdust rice husks peanut shells coffee grounds and bagasse into valuable fuel
• Export Market: Produce export-quality briquettes for European and Asian buyers

• Hydraulic Pressing System: Provides 25 tons of pressing force without mechanical wear issues common in screw presses
• No Binder Required: The high pressure (25 tons) naturally binds lignin in biomass eliminating chemical additives
• Low Energy Consumption: Only 22 kWh per ton of briquettes (50% less than screw type briquette machines)
• Wear-Resistant Components: Hydraulic cylinder with hardened chrome-plated piston rod lasting 8000+ hours
• Automatic Cooling System: Oil cooler maintains hydraulic fluid temperature below 60°C for continuous operation
• Dense Briquette Output: Final briquette density reaches 1.1-1.3 g/cm³ with calorific value of 4500-5000 kcal/kg

• Hydraulic briquette machine main unit *1
• Briquette die (size of your choice) *1
• Spare piston seals kit *1
• Hydraulic oil (pre-filled) *1 batch
• Operation manual (English) *1
• Tool kit for maintenance *1
• 18-month warranty card *1

• Payback period: Typically 6-9 months for users processing 3 tons per day
• Briquette durability: Survives 2-meter drop test without breakage
• Moisture tolerance: Works consistently with 8%-12% moisture range
• Export ready: CE certified with wooden crate packaging for sea freight

To receive a customized quote including shipping to your port please provide:

• Raw material type (e.g. rice husks sawdust coffee grounds)
• Daily production target (tons per day)
• Local voltage and frequency (e.g. 415V/50Hz 220V/60Hz)
• Desired briquette diameter (50mm 70mm or 80mm)
• Delivery port (e.g. CIF Hamburg FOB Shanghai)

• Exact price (FOB/CIF/CNF)
• Recommended model based on your material
• Optional equipment (hammer mill dryer cooler)
• Sea freight cost and estimated arrival time
• Video of machine testing your material (available on request)
