Qualified SS316L Wedge Wire Header Lateral Assemblies for Oil Refining Filter Systems

Header lateral assemblies are critical components in industrial filtration vessels for oil and water distribution. Huatao assemblies by Huatao Group are constructed from premium Stainless Steel 316L to ensure anti-rust and anti-corrosion performance. This material is chosen for its chemical stability, featuring a high Nickel content of 10.0–14.0%.

The technical core is the high strength and rigidity of the wedge wire design. These assemblies feature continuous V-shaped profile wires welded to internal support rods, ensuring uniform flow distribution across the entire bed. This design effectively minimizes contact between the filtering media and the slot, providing an anti-clogging performance that is superior to standard perforated pipes. The opening gaps are precisely controlled, making them suitable for high-precision petrochemical applications.

As a source factory, we support full customization of all technical parameters, including lateral lengths, thread types, and wire diameters (1.2mm–4.0mm). Our assemblies are designed to withstand high flow rates and are tested for structural stability. Each assembly meets Grade 1 industrial safety standards, ensuring reliable operation in refinery filtration systems.

• Corrosion-Resistant Material Selection: In water treatment and sludge dewatering, exposure to moisture and chemicals is constant. We utilize SS 304 and 316L stainless steel to ensure our screens survive these environments. This meticulous selection protects the purity of the filtered media and ensures a long usage time, even in non-stop 24/7 operations.
•  Fine Workmanship for High Throughput: Our welded wedge wire features a perfectly flat surface and uniform gaps. This is critical for "High Drainage Efficiency", as it allows for the rapid transit of liquids while the trapezoidal (V-shaped) wire section prevents material buildup.
• Stable Performance Across Diverse Loads: With high toughness and rebound resilience, our panels are resistant to deformation during high-volume screening. They are rated for a filtration precision range of 25-800 micrometers, making them suitable for everything from fine grain polishing to heavy industrial waste filtration.
• Direct Factory Customization: Huatao serves as a source factory, supporting full customization of wire diameters (1.6mm-4.0mm) and pore sizes (down to 0.5mm). This ensures that our screens can be adapted to the specific viscosity and particle size of any industrial media.
