Hard Chromium Plating Induction Heating Roller Electromagnetic Induction Heating

Large Image : Hard Chromium Plating Induction Heating Roller Electromagnetic Induction Heating

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	ELECTROMAGNETIC INDUCTION HEATING ROLLER

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2000USD/pc-5000USD/pc
Packaging Details:	Wooden Box
Delivery Time:	5-8 weeks
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	100 PCS/Year

Contact Now

Detailed Product Description

Product Name:	Hard Chromium Plating Induction Heating Roller Electromagnetic Induction Heating	Key Words:	Electromagnetic Induction Heating Roller, Heating Roller
Processing Accuracy:	Roller Surface Temperature Difference ≦±1℃	Straightness Runout:	≤0.01mm
Material:	High-quality 45# Steel, Alloy Steel, And High-quality Steel	Heating Method:	Electromagnetic Induction Heating
Surface Treatment:	Hard Chromium Plating, Teflok, Spray Ceramic Or Tungsten Carbide
Highlight:	Hard chromium plating industrial roller , Electromagnetic induction heating roller , Induction heating roller with warranty

Hard Chromium Plating Induction Heating Roller Electromagnetic Induction Heating

Electromagnetic Roller Heating Core Merits

Consistent Surface Heating Effect: Advanced induction electromagnetic heating balances thermal spread on rollers of any size, restricting temperature inconsistency to ±1°C, suited for low, medium and high-temperature industrial processing. Ultra-Fine Thermal Control Accuracy: High-resolution temperature sensors limit temperature drift to merely 0.1℃. Ceramic insulating layers and water-cooled coil assemblies allow stable continuous operation under temperatures up to 600°C. Risk-Free Safe Operation: Pure electromagnetic heating design circumvents common safety hazards of oil heating equipment: pressure distortion, tank rupture and heat medium leakage. Low-Carbon Environmental Performance: Removes heat transfer oil and steam circulation entirely, so there are no fluid spills, industrial contaminants or toxic gas emissions throughout operation. Exceptional Energy Efficiency: Delivers 50% to 70% power savings over legacy heating equipment, with heating ramp speed twice faster than traditional roller heating units.

Technical Specifications

Material	High-quality 45# steel, alloy steel
Roller Surface Temperature Difference	≦±1℃
Heating Method	Electromagnetic induction heating
Surface Treatment	Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Processing Accuracy	≤0.005mm
Straightness Runout	≤0.01mm

Application Fields

Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.

About Huatao Group

Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
