Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5

Large Image : Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5

Product Details:

Place of Origin:	CHINA
Brand Name:	Cooling Roller For Bopp Bopet Film
Certification:	ISO CE Pressure Test
Model Number:	Cooling Roller For Bopp Bopet Film

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	30000-5000 USD/PC
Packaging Details:	Wooden Case
Delivery Time:	3-5 Month
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	50 PCS PER MONTH

Contact Now

Detailed Product Description

Product Name:	Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5	Key Words:	Cooling Roller Bopp Bopet
Flow-System:	Channels Between Inner And Outer Tube Separated With Welded Leading Spirals	Inner And Outer Tube:	S355
Double-shell Construction Type:	2OS	Balance:	G2.5
Cylinder Form:	<=0.1mm	Disc/Shaft Construction:	Disc/Shaft Construction
Out Of Roundness:	<=0.1mm
Highlight:	Shaft Construction Cooling Roller , BOPP BOPET Film Roller , Industrial Roller with G2.5 Balance

Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5

Cooling Roller Product Brief

In industrial production, heat transfer cooling rollers adopt two core internal structural forms: double-layer single-flow and double-layer double-flow systems, with water and heat transfer oil serving as the conventional heat exchange media. The two structural types differ greatly in internal layout design and manufacturing techniques, directly leading to obvious cost discrepancies in batch production and processing.

1. Internal Structure of Double-layer Single-flow Heat Transfer Roller: The single-flow cooling roller is assembled with an outer shell, an inner shell and matched spiral baffles on the inner shell wall. The heat exchange medium is injected into the internal single-loop heat conduction pipeline via the external pipe fitting and completes unidirectional circulating flow inside the roller. The medium flows out from the opposite side wall after full heat exchange, effectively absorbing and removing residual heat to achieve the equipment cooling effect.

2. Internal Structure of Double-layer Double-flow Heat Transfer Roller: Retaining the basic outer and inner shell structure with spiral baffles, this double-flow roller optimizes the internal circulation system and adopts a unique double-layer dual-channel circulation structure. The aluminum alloy roller body supports dual-path medium circulation. Water or heat transfer oil flows into the two sets of internal heat conduction channels for synchronous circulating heat exchange. It boasts remarkable heat dissipation and heat transfer performance, but the intricate production and processing technology inevitably raises its manufacturing difficulty and comprehensive cost.

Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5 0

Cooling Roller Production Crafts:

Double-shell construction type	2OS
Inner and outer tube Material	Q345B
Flow-System	channels between inner and outer tube separated with welded leading spirals
Disc/Shaft construction	Shrinked and welded shafts and side discs from Q345B
SURFACE:	chrome-coating, ceramic-coating, anti-sticking coating
cylinder form	<=0.1mm
Out of roundness	<=0.1mm
Dynamic balancing	G2.5

Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5 1

Shaft Construction Cooling Roller Bopp Bopet Film Balance G2.5 2
