High-Quality Alloy Steel Induction Heating Roller Hard Chromium Plating

Large Image : High-Quality Alloy Steel Induction Heating Roller Hard Chromium Plating

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	ELECTROMAGNETIC INDUCTION HEATING ROLLER

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2000USD/pc-5000USD/pc
Packaging Details:	Wooden Box
Delivery Time:	5-8 weeks
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	100 PCS/Year

Contact Now

Detailed Product Description

Product Name:	High-Quality Alloy Steel Induction Heating Roller Hard Chromium Plating	Processing Accuracy:	Roller Surface Temperature Difference ≦±1℃
Thermal Deformation:	≤0.01mm	Surface Treatment:	Hard Chromium Plating, Teflok, Spray Ceramic Or Tungsten Carbide
Material:	High-quality 45# Steel, Alloy Steel, And High-quality Steel	Heating Method:	Electromagnetic Induction Heating
Key Words:	Electromagnetic Induction Heating Roller, Heating Roller
Highlight:	alloy steel induction heating roller , hard chromium plating industrial roller , industrial roller with induction heating

High-Quality Alloy Steel Induction Heating Roller Hard Chromium Plating

Product Features

Temperature uniformity performance: By adopting mature electromagnetic induction heating solution, surface temperature variation is controlled within ±1°C regardless of roller overall dimension. It can meet process requirements under low‑temperature, medium‑temperature and high‑temperature working scenarios.
Temperature control precision: Utilizing high‑precision sensing elements, cooperating with ceramic insulation structure and water‑cooled coil assembly, the system realizes 0.1℃ control accuracy, with allowable maximum stable operating temperature of 600°C.
Safety performance: Pure electromagnetic heating principle avoids potential safety risks brought by thermal oil circulation system, including component deformation caused by internal pressure, explosion possibility and circulating‑medium leakage.
Environmental protection attribute: The product does not rely on heat transfer oil or steam as heat medium; there exists no risk of medium leakage, on‑site contamination and hazardous substance emission.
Energy‑saving index: Relative to conventional heating equipment, energy consumption can be decreased by 50‑70%, meanwhile heating response speed is doubled.

Technical Specifications

Material	High-quality 45# steel, alloy steel
Roller Surface Temperature Difference	≦±1℃
Heating Method	Electromagnetic induction heating
Surface Treatment	Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Processing Accuracy	≤0.005mm
Straightness Runout	≤0.01mm

Application Fields

Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.

About Huatao Group

Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
