Home ProductsPaper Making Machine

Auto Reeling Pope Reel Winder Paper Machine Iso9001

China HUATAO LOVER LTD certification
China HUATAO LOVER LTD certification
Huatao company is a very good company , I am very willing to cooperate with you, safe, efficient, professional, honest, happy! Thank you for providing me with stable service and products. -----EUROPAT

—— EUROPT INDUSTRIAL

I'm Online Chat Now

Auto Reeling Pope Reel Winder Paper Machine Iso9001

Auto Reeling Pope Reel Winder Paper Machine Iso9001
Auto Reeling Pope Reel Winder Paper Machine Iso9001 Auto Reeling Pope Reel Winder Paper Machine Iso9001

Large Image :  Auto Reeling Pope Reel Winder Paper Machine Iso9001

Product Details:
Place of Origin: CHINA
Brand Name: HUATAO
Certification: ISO9001
Model Number: Paper Machine Auto Reeling Machine Winder Pope Reel
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 5000USD/set
Packaging Details: Standard export packing
Delivery Time: 120 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 sets per month
Detailed Product Description
Product Name: Paper Machine Auto Reeling Machine Winder Pope Reel Application: Paper Machine - Paper Collection, Winder
Paper Grade: 15gsm - 360gsm Paper Type: Tissue, Kraft, Testliner, Printing And So On.
High Light:

auto reeling winder paper machine

,

pope reel winder paper machine

Paper Machine Auto Reeling Machine Winder Pope Reel For Paper Machine



Paper Machine Auto Reeling Machine Winder Pope Reel Description

This machine is used for the first set of finishing equipment behind the paper machine. The roll cylinder is operated actively, and the roll is driven by friction to complete the paper winding. By adjusting the pressure of the auxiliary arm and the cylinder of the main arm to adjust the linear pressure between the roll and the cylinder, the operation can meet the needs of different kinds of paper and make the paper rolled down from the paper machine into a compact and uniform roll paper.



Roller library type paper roll machine with the same net paper width of the paper machine, used for the paper machine copied from the width of the paper roll into a tight uniform paper roll. It has the characteristics of reliable and convenient storage of replacement roll. The equipment mainly consists of the main frame, a paper cylinder device, a stretcher roller device, the main arm device, a secondary arm device, a pneumatic scraper device, and so on. When the machine is running, the paper roll is driven to rotate by the friction of the surface against the rotating cylinder.



Technical details of Paper Machine Auto Reeling Machine Winder Pope Reel

Product Name Paper Machine Auto Reeling Machine Winder Pope Reel For Paper Machine
Net paper width 1092 - 5600mm
Working speed m/min customization, suitable for your current paper machine
Paper gsm 15gsm - 360gsm
Paper type Tissue, Kraft, Testliner, Printing & Writing, culture paper, and so on.
Max Jumbo Roll diameter 2800mm



Working theory of Horizontal pneumatical Paper Machine Auto Reeling Machine Winder Pope Reel
The winding roller is driven to wind paper by a cooling drum, the cooling cylinder is equipped with a driving motor. In working, the linear pressure between the paper roll and cooling drum can be adjusted by controlling the air pressure of the main arm and vice arm air cylinder.



Paper Machine Auto Reeling Machine Winder Pope Reel Feature
high working speed,no-stop, save paper, shorten paper roll changing time, neat tight big paper roll, high efficiency, easy operation.



Auto Reeling Pope Reel Winder Paper Machine Iso9001 0

Auto Reeling Pope Reel Winder Paper Machine Iso9001 1



Paper Machine Auto Reeling Machine Winder Pope Reel Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing the most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technicians.



Paper Machine Auto Reeling Machine Winder Pope ReelAfter-Sales Service
Highly inspecting equipment in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients with foundation construction of equipment;
Dispatching engineers to install and debug the equipment;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchange;
