High Speed Pulp Washer Equipment For Paper Making

High Speed Pulp Washer Equipment For Paper Making
High Speed Pulp Washer Equipment For Paper Making High Speed Pulp Washer Equipment For Paper Making High Speed Pulp Washer Equipment For Paper Making

Large Image :  High Speed Pulp Washer Equipment For Paper Making

Product Details:
Place of Origin: China
Brand Name: HT
Certification: SGS,ISO
Model Number: HT001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Can negotiate
Packaging Details: Wooden Box
Delivery Time: 5 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detailed Product Description
Type: Pulping Equipment Dimension(L*W*H): Depend On The Type
Voltage: 220V Computerized: No
Function: Breaking And Filtrating Waste Paper Processing Capacity(t/d): 220-1200
Application: Paper Making Pulp Equipment Raw Material: OCC
Certification: ISO9001:2008
High Light:

pulp chest agitator

,

pulp and paper machinery



High Speed Pulp Washer Equipment For Paper Making



Type: Pulping Equipment

Computerized: Yes

Voltage: 220V

Power(W): 5.5KW

Dimension(L*W*H): Configuration

Weight: 500kg

Certification: ISO9001:2008

Product name: Pulp Washer

Control system: PLC System

Quality: Top quality

Customized: Accepted

Service time: All life

Raw material: Stainless Steel

Application: Paper making pulp equipment

Color: Customized

Feeding content: 0.3-1%

The consistency of pulp leaving: 8-12

After-sales Service Provided: Engineers available to service machinery overseas



1



first:

Product Profile:
High speed pulp washer is a washing equipment used in paper making industry in China, on the basis of advanced foreign technology, successfully developed a new type of Deinked pulp washing equipment.

Complete machine adopts full closed-end structure, stainless steel shell shape can replace the condenser and the inclined screw thickeners, simplifies the process and reduces costs.





Application:
It is used for washing and thickening in waste paper pulp processing.



Performance characteristics:

The advanced equipment manufacturing, high degree of automation. Single machine can realize the size change from low concentration to high concentration, concentration, ash removal efficiency high, washing efficiency; to efficiently remove ink, fillers and other tiny impurities, improving the whiteness of the pulp. Due to the simple structure, small size, high efficiency, Deinked pulp processing system has been widely used in.



the second:

Product Profile:

It is used washing and thickening in waste paper pulp processing



Features:

Pressure type guniting , pulp thick and well-distributed

High speed ,twinver com-press, pulp dewatering fast , high rate ash removal.

Equipped automatic correction device ,adopted eletromagnetic motor speed control ,easy operation and working safety





the third:

Product Profile:

High Speed Pulp Washing Machine is a new generation of washing and concentrating equipment. It can not only wash, but also concentrate, high efficiency of impurity removal and dehydration effect, obvious water-saving effect, especially suitable for waste paper deinking pulp and concentration.



Features:

The equipment has high deinking efficiency for small impurities such as ink ions and filler, etc. It can be widely applied to the washing and concentration of recycled pulp for waste newsprint, waste books and periodicals.



 The fourth:

Application:

it is able to wash and thicken waste paper pulp efficiently through the centrifugal force generated by the high speed rotation of rubber covered roller, as well as the extrusion force between the roller and the net.



Features:

high washing efficiency, small floor coverage, easy installation and operation, rarely fiber waste

High Speed Pulp Washer Equipment For Paper Making 0



Type HT-4025 HT-4525 HT-5030 HT-5530 HT-6030
Filtrating area: m2 40 45 50 55 60
Consistency of inflow pulp: % 0.5-1
Consistency of outflow pulp: % 4-6
Capacity of product: Rich-wheat-straw pulp: t/d 40-60 45-67 50-75 55-82 60-90
Mixed waste paper: t/d 60-80 67-90 75-100 82-110 90-120
Reed pulp: t/d 80-100 90-112 100-125 110-137 120-150
Chemical wood pulp: t/d 120-140 135-157 150-175 165-192 180-210
Power of motor: kw 15 18.5 22
