Home ProductsCorrugator Belt

10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber

China HUATAO LOVER LTD certification
China HUATAO LOVER LTD certification
Huatao company is a very good company , I am very willing to cooperate with you, safe, efficient, professional, honest, happy! Thank you for providing me with stable service and products. -----EUROPAT

—— EUROPT INDUSTRIAL

I'm Online Chat Now

10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber

10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber
10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber 10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber

Large Image :  10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber

Product Details:
Place of Origin: CHINA
Brand Name: HUATAO
Certification: ISO9001
Model Number: HT-002
Payment & Shipping Terms:
Minimum Order Quantity: No MOQ
Price: USD 50-150/M2
Packaging Details: Waterprooffilm+Dampblanket+Plasticbag+woodpackage+pallet
Delivery Time: 15-20 DAYS
Payment Terms: Western Union, T/T, L/C
Supply Ability: 40000M2/Year
Detailed Product Description
Product: Cotton Corrugator Belt 10mm Thickness Kevlar Edges High Temperature Resistance Up Tp 350 Degree Centigrade Thickness: 10mm
Width Range: 1000mm - 3200mm Heat Resistance: 220℃ (Edge Part Up To 350℃)
Weight: 7.5kg/㎡ Suitable Speed: ≤ 300m/min
Color: White, Yellow Edges: Weaved Edges
Material: Cottom Fiber
High Light:

Kevlar Edges Corrugated Belt

,

10mm Thickness Corrugated Belt

,

10mm Thickness Corrugator Belt

60% Cotton 40% Synthetic Fiber 10mm Thickness Kevlar Edges Cotton Corrugated Belt



Cotton Corrugator Belt Descripation:



HUATAO corrugated cardboard conveyor belt is developed for the corrugated cardboard production line and is dedicated to double-sided machines. The four functions of the conveyor belt are smooth cardboard conveying, straight running, evenly distributing the pressure of the pressure system to the hot plate and ensuring the best cardboard dryness.

Conveyor belts are usually subjected to high temperature, high humidity, high friction and pressure from the pressure system during operation. The conveyor belts of Mirrensson are woven from fracture-resistant, high-temperature and abrasion-resistant fibers. The high-quality raw materials give the conveyor belts extremely strong friction and paper-carrying capabilities. This provides a safe and reliable guarantee for the smooth production of your tile line.



How To Clean and Maintenance Of Cotton Corrugator Belt?



It is better to thoroughly clean the cotton corrugator belt once time per month. Here are some detail steps:
1. Keep the machine running with slow speed;

2. Make the corrugator belt fully moist by water or low pressure steam spray with much water content;
3. Put into some detergent and clear up the dirt & paste scar with soft brush;
4. After cleaning,using water to wash the belt again;
5. During the washing process,it will be greatly help to lay out shallow U-shaped iron plate or shallow groove under the corrugator belt.It will make the cleaning water flow out to the machine outside,keep the heating panel clear and no any corrosion;
6. When necessary, you can turn on steam to heat the heating panel and make the wet corrugator belt drying with slow speed.



Corrugated Belt Specifications:



Material 60% cotton 40%synthetic fiber
Thickness 9.5+-0.3mm
Width range 1000mm - 3200mm
Heat resistance 230℃ (edge part up to 350℃)
Weight 7.5kg/㎡
Suitable speed ≤ 300m/min
Belt Seam

Hot Clipper Lacing With Flocking or

Clipper Steel covered with cloth

Position Top belt and bottom belt





Cotton Corrugator Belt Installation pictures from our partners:





10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber 010mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber 1







Cotton Corrugator Belts Package :



Type-I:Waterproof film+Dampblanket+Plasticbag+pallet

Type-II:Waterprooffilm+Dampblanket+Plasticbag+woodpackage+pallet

10mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber 210mm Thickness Kevlar Edges Corrugated Belt 60% Cotton 40% Synthetic Fiber 3







Cotton Corrugator Belt Offer inquiry information



1. Your corrugator brand & Running speed :

2. Top corrugator belt size :

3. Lower Corrugator belt size :



Advantages of  Cotton Corrugator Belt:



(1) Not sensitive to external interference
(2) High moisture absorption fiber is used to improve the moisture absorption and dehumidification capacity of the conveyor belt
(3) High friction coefficient = strong paper-carrying ability, even and firm adhesion of cardboard
(4) Running straight
(5) Smooth operation-low noise
(6) Suitable for all kinds of tile wires, repairable after damage, less trimming
(7) Ultrahigh speed
(8) Suitable for mixed order production
(9) Reduce scrap rate by 50%
