Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter

Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter
Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter

Large Image :  Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter

Product Details:
Place of Origin: China
Brand Name: Huatao
Certification: ISO
Model Number: HT-RC-02
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Price accept negotiation
Packaging Details: Wooden box
Delivery Time: 15-20 working days
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 100 units per month
Detailed Product Description
Shell Material: Cast Aluminium Contact Medium Part Material: Stainless Steel
Measure Range: 1%-6% Analog Signals: 4-20mA
Repeat Accuracy: 0.2% Digital Signal: RS422
Color: Blue, Red Cycle Time: 1-20 S
Ratio: 0-100
High Light:

pasting belt

,

synthetic conveyor belt

Pneumatic Inline Measurement Active Blade Consistency Transmitter For Paper Pulp Production





Product description of Consistency Transmitter



Consistency transmitters use reciprocating, active sensors to measure concentration using the principle of shear force. This shear force measurement method makes the transmitter substantially insensitive to normal changes in fiber composition, freeness, filler, black liquor content, flow rate, air content, pressure, etc.





Technical parameters of Consistency Transmitter



Product name Consistency Transmitter
Shell Material Cast aluminium
Contact medium part material Stainless steel
Measure range 1%-6%
Analog signals 4-20mA
Damping time 1~100s
Working temperature 1MPa, 80°C
Sensor power 380V
Sensitivity Up to 0.01%
Characteristic and advantages
  • Liquid crystal display, which can realize multi-point, parabolic calibration and easy to operate calibration
  • Signal damping and filtering are very low, signal to noise ratio is high, and has high precision
  • Not affected by pulp, fiber type, freeness, Kappa number, flow rate, pressure, etc
  • It is little affected by pH and temperature, and the temperature can be compensated
  • Unaffected by pressure, air bubbles, and electrical conductivity
  • Fast response, short reaction time and control dead time, and good controllability
  • It can be installed on horizontal, vertical, or inclined pipes. The sensor shaft should be horizontal and the motor should be under the sensor





Product Advantages of Consistency Transmitter



  • Liquid crystal display, which can realize multi-point, parabolic calibration and easy to operate calibration
  • Signal damping and filtering are very low, signal to noise ratio is high, and has high precision
  • Not affected by pulp, fiber type, freeness, Kappa number, flow rate, pressure, etc
  • It is little affected by pH and temperature, and the temperature can be compensated
  • Unaffected by pressure, air bubbles, and electrical conductivity
  • Fast response, short reaction time and control dead time, and good controllability
  • It can be installed on horizontal, vertical, or inclined pipes. The sensor shaft should be horizontal and the motor should be under the sensor



Detailed photos of Consistency Transmitter



Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter 0

Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter 1

Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter 2

Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter 3

Pneumatic Inline Measurement Stainless Steel Active Blade Consistency Transmitter 4
