43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade

43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade
43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade 43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade

Large Image :  43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade

Product Details:
Place of Origin: CHINA
Brand Name: HUATAO
Certification: ISO9001
Model Number: HT1500
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 15000/SET
Packaging Details: Standard export packing
Delivery Time: 30days
Payment Terms: L/C, T/T
Detailed Product Description
Package: Wooden Case Voltage: 380V, Other Voltage Need Customize
Total Power: 43kw Weight: 4.15t
Transport Package: Plastic Film And Wooden Box Origin: China
Color: Optional Frequency: 43-60Hz Can Customize
Trademark: Huatao HS Code: 8443139000
High Light:

43kw slitter cutting machine

,

380v slitter cutting machine

,

jumbo roll slitter cutting machine

43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade

Jumbo Roll Slitter description

Every day, millions of papers are cut into pieces & rolls by roll paper cutting machines. We are one of the leading manufacturers of paper reel-to-sheet cutting machines. The offered cutting machines are specially manufactured by using top-notch components along with the latest technology.



This paper-slitting machine can cut different-width paper rolls and provide on-site roll paper-cutting processing services. It is widely used in paper mills, packaging, and printing factory for cutting paper rolls that are soaked, wormed, bigger, or special specifications according to customer demands, also including kraft paper, corrugated paper, white cards, etc.



WHEN CHOOSING THE PAPER Jumbo Roll CUTTER MACHINE, HERE ARE FIVE FACTORS YOU SHOULD CONSIDER:

  1. What size material will you be cutting?
  2. Which types of material will you be cutting?
  3. How much time will be spent cutting?
  4. Is the machine supported with service and spare parts?
  5. Does it meet current safety standards?



KEY FEATURES AT Jumbo Roll Slitter

  1. Flat and smooth cut surface;
  2. The blade loss is 2MM;
  3. Fully automated operation;
  4. Paper recycling rate is as high as 95%;
  5. Tailored according to customer requirements (base paper specifications);
  6. All parts materials are durable and wear-resistant, and we provide good after-sales service;
  7. Machinery will provide the best paper cutting solution for you, we have the perfect after-sales service and technical support.

Jumbo Roll Slitter Technology Parameters

Machine Name Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade
Paper Width Between 3cm to 2.80m
Paper Roll Diameter Between 35cm to 1.35m
Time-consuming

It'll take 5min to cut 1.25m DIA and 140g Kraft cardboard, time-consuming conversely to weight. 6 rolls can be cut per hour on average

Cutting Diameter 450-1350mm
Max Cutting Length 3000mm
Alloy Steel Saw Head Taiwan
Saw Style Model 1750mm*10.5mm Imported tungsten steel saw head
Size of machine (L*W*H) 4000mm*2200mm*2500mm
Voltage 380V(standard), other voltage need customize
Frequency 50-60HZ can customize
Total Power 43KW
Main Motor Power

22KW

Weight

4.15T



43kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade 043kw Paper Jumbo Roll Slitter Cutting Machine With Electric Circular Saw Blade 1

FAQ

Q: How to confirm the type?
A: There are many methods for us to confirm the type:
Way 1, tell us the specifications data.
Way 2, tell us your requirements as more as possible, and our engineers will give you the best solution.

Q: What is the payment terms?
A: We prefer T/T, but for some countries, we will also accept L/C. So pls feel free about the payment.

Q: When will delivery the goods?
A: Usually, we will deliver the goods within 30 working days.

Q: How long will the fabric be used?
A: The time is different differ the usage and factory. But we can confirm and make sure that our product can be used longer than any other one in China.
