45 Steel Alloy Steel And Steel Electromagnetic Induction Heating Roller Hard Chromium Plating

Large Image : 45 Steel Alloy Steel And Steel Electromagnetic Induction Heating Roller Hard Chromium Plating

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	ELECTROMAGNETIC INDUCTION HEATING ROLLER

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2000USD/pc-5000USD/pc
Packaging Details:	Wooden Box
Delivery Time:	5-8 weeks
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	100 PCS/Year

Contact Now

Detailed Product Description

Product Name:	45 Steel Alloy Steel And Steel Electromagnetic Induction Heating Roller Hard Chromium Plating	Heating Method:	Electromagnetic Induction Heating
Key Words:	Electromagnetic Induction Heating Roller, Heating Roller	Thermal Deformation:	≤0.01mm
Processing Accuracy:	Roller Surface Temperature Difference ≦±1℃	Surface Treatment:	Hard Chromium Plating, Teflok, Spray Ceramic Or Tungsten Carbide
Material:	High-quality 45# Steel, Alloy Steel, And High-quality Steel
Highlight:	45 steel alloy induction heating roller , steel electromagnetic induction roller , hard chromium plating industrial roller

45 Steel Alloy Steel And Steel Electromagnetic Induction Heating Roller Hard Chromium Plating

Product Features

Our electromagnetic induction heating rollers deliver outstanding temperature‑equalizing performance. Adopting cutting‑edge electromagnetic induction technique, the whole roller surface keeps heat deviation controlled at ±1°C regardless of roller dimension, fitting low‑, medium‑ and high‑temperature process scenarios. Equipped with high‑precision sensing components together with ceramic insulation and water‑cooled coil structure, the system achieves 0.1℃ temperature control accuracy and can run steadily under working temperature as high as 600°C. Different from thermal‑oil heating solutions, pure electromagnetic heating removes hidden hazards including pressure‑caused deformation, burst risk and medium leakage. Without heat transfer oil or steam medium, zero leakage and pollutant emission can be realized for eco‑friendly operation. Meanwhile, the heating rate doubles versus conventional solutions while cutting energy consumption by 50‑70%.

Technical Specifications

Material	High-quality 45# steel, alloy steel
Roller Surface Temperature Difference	≦±1℃
Heating Method	Electromagnetic induction heating
Surface Treatment	Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Processing Accuracy	≤0.005mm
Straightness Runout	≤0.01mm

Application Fields

Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.

About Huatao Group

Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
