Tungsten Carbide Induction Heating Roller Hard Chromium Plating Teflok Spray Ceramic

Large Image : Tungsten Carbide Induction Heating Roller Hard Chromium Plating Teflok Spray Ceramic

Product Details:

Place of Origin:	CHINA
Brand Name:	HUATAO
Certification:	ISO
Model Number:	ELECTROMAGNETIC INDUCTION HEATING ROLLER

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2000USD/pc-5000USD/pc
Packaging Details:	Wooden Box
Delivery Time:	5-8 weeks
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	100 PCS/Year

Contact Now

Detailed Product Description

Product Name:	Tungsten Carbide Induction Heating Roller Hard Chromium Plating Teflok Spray Ceramic	Processing Accuracy:	Roller Surface Temperature Difference ≦±1℃
Heating Method:	Electromagnetic Induction Heating	Thermal Deformation:	≤0.01mm
Surface Treatment:	Hard Chromium Plating, Teflok, Spray Ceramic Or Tungsten Carbide	Material:	High-quality 45# Steel, Alloy Steel, And High-quality Steel
Key Words:	Electromagnetic Induction Heating Roller, Heating Roller
Highlight:	Tungsten Carbide Induction Heating Roller , Hard Chromium Plating Industrial Roller , Teflok Spray Ceramic Roller

Tungsten Carbide Induction Heating Roller Hard Chromium Plating Teflok Spray Ceramic

Product Features

Consistent Temperature Performance Thanks to state‑of‑the‑art electromagnetic induction heating, temperature deviation on roller surface stays within ±1°C for any roller diameter and length. Compatible with full‑range low‑to‑high‑temperature production requirements.
Ultra‑Accurate Temperature Regulation High‑accuracy sensing hardware, matched with ceramic insulating material and water‑cooled coil construction, realizes 0.1℃ temperature control tolerance. The equipment can sustain reliable long‑time operation at temperatures as high as 600°C.
Optimized Operational Safety Pure electromagnetic heating mode abandons thermal‑oil circulation, effectively preventing potential failures such as pressure‑induced deformation, explosion accidents and medium leakage.
Environment‑Friendly Design Heat transfer oil and steam are completely eliminated from the system. There will be no medium spillage, site pollution or hazardous gas discharge during equipment running.
Outstanding Energy‑Saving Effect When compared with conventional heating approaches, energy consumption drops by 50‑70%. The heating speed can reach twice that of traditional equipment.

Technical Specifications

Material	High-quality 45# steel, alloy steel
Roller Surface Temperature Difference	≦±1℃
Heating Method	Electromagnetic induction heating
Surface Treatment	Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Processing Accuracy	≤0.005mm
Straightness Runout	≤0.01mm

Application Fields

Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.

About Huatao Group

Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
